Nix Flakes Explained

This explanation highlights common areas of confusion for those new to Nix Flakes, aiming to clarify concepts rather than serve as a comprehensive guide.

What is a Nix Flake?

At its core, a flake is a source tree (like a Git repository) that contains a flake.nix file. This file provides a standardized way to access Nix artifacts such as packages and modules.
Think of flake.nix as the central entry point of a flake. It not only defines what the flake produces but also declares its dependencies.

Key Concepts

** flake.nix: The Heart of a Flake**

The flake.nix file is mandatory for any flake. It must contain an attribute set with at least one required attribute: outputs. It can also optionally include description and inputs.
Basic Structure:

{
  description = "Package description";
  inputs = { /* Dependencies go here */ };
  outputs = { /* What the flake produces */ };
  nixConfig = { /* Advanced configuration options */ };
}

Attribute Sets: The Building Blocks

Attribute sets are fundamental in Nix. They are simply collections of name-value pairs wrapped in curly braces {}.
- Example:
```
let
  my_attrset = { foo = "bar"; };
in
my_attrset.foo
```
- Output:
```
"bar"
```
Top-Level Attributes of a Flake:
- Flakes have specific top-level attributes that can be accessed directly (without dot notation). The most common ones are inputs, outputs, and nixConfig.

Anatomy of `flake.nix`

inputs: Declaring Dependencies

The inputs attribute set specifies the other flakes that your current flake depends on.
Each key in the inputs set is a name you choose for the dependency, and the value is a reference to that flake (usually a URL or a Git Repo).
To access something from a dependency, you generally go through the inputs attribute (e.g., inputs.helix.packages).
- Example: This declares dependencies on the nixpkgs and import-cargo flakes:
```
inputs = {
  import-cargo.url = "github:edolstra/import-cargo";
  nixpkgs.url = "nixpkgs";
};
```
- When Nix evaluates your flake, it fetches and evaluates each input. These evaluated inputs are then passed as an attribute set to the outputs function, with the keys matching the names you gave them in the inputs set.
- The special input self is a reference to the outputs and the source tree of the current flake itself.

outputs: Defining What Your Flake Provides

The outputs attribute defines what your flake makes available. This can include packages, NixOS modules, development environments (devShells) and other Nix derivations.
Flakes can output arbitrary Nix values. However, certain outputs have specific meanings for Nix commands and must adhere to particular types (often derivations, as described in the output schema).
You can inspect the outputs of a flake using the command:

nix flake show

This command takes a flake URI and displays its outputs in a tree structure, showing the attribute paths and their corresponding types.

Understanding the outputs Function

Beginners often mistakenly think that self and nixpkgs within outputs = { self, nixpkgs, ... }: { ... } are the outputs themselves. Instead, they are the input arguments (often called output arguments) to the outputs function.
The outputs function in flake.nix always takes a single argument, which is an attribute set. The syntax { self, nixpkgs, ... } is Nix’s way of destructuring this single input attribute set to extract the values associated with the keys self and nixpkgs.

Referencing the Current Flake (self)

self provides a way to refer back to the current flake from within the outputs function. You can use it to access other top-level attributes like inputs (e.g., self.inputs).
The outputs function always receives an argument conventionally named self, which represents the entire flake, including all its top-level attributes. You’ll typically use self to reference things defined within your own flake (e.g., self.packages.my-package).

Variadic Attributes (…) and @-patterns

The ... syntax in the input arguments of the outputs function indicates variadic attributes, meaning the input attribute set can contain more attributes than just those explicitly listed (like self and nixpkgs).
Example:
```
mul = { a, b, ... }: a \* b;
mul { a = 3; b = 4; c = 2; } # 'c' is an extra attribute
```
However, you cannot directly access these extra attributes within the function body unless you use the @-pattern:
```
mul = s@{ a, b, ... }: a _ b _ s.c; # 's' now refers to the entire input set
mul { a = 3; b = 4; c = 2; } # Output: 24
```
- When used in the outputs function argument list (e.g., outputs = { pkgs, ... } @ inputs), the @-pattern binds the entire input attribute set to a name (in this case, inputs) while also allowing you to destructure specific attributes like pkgs.
- What outputs = { pkgs, ... } @ inputs: { ... }; does:

Destructuring: It tries to extract the value associated with the key pkgs from the input attribute set and binds it to the variable pkgs. The ... allows for other keys in the input attribute set to be ignored during this direct destructuring.
Binding the Entire Set: It binds the entire input attribute set to the variable inputs.
- Example flake.nix:

{
inputs.nixpkgs.url = "github:NixOS/nixpkgs/nixos-unstable";
inputs.home-manager.url = "github:nix-community/home-manager";

outputs = { self, nixpkgs, ... } @ attrs: { # A `packages` output for the x86_64-linux platform
packages.x86_64-linux.hello = nixpkgs.legacyPackages.x86_64-linux.hello;

    # A `nixosConfigurations` output (for a NixOS system named "fnord")
    nixosConfigurations.fnord = nixpkgs.lib.nixosSystem {
      system = "x86_64-linux";
      specialArgs = attrs;
      modules = [ ./configuration.nix ];
    };

};
}

Platform Specificity in Outputs

Flakes ensure that their outputs are consistent across different evaluation environments. Therefore, any package-related output must explicitly specify the target platform (a combination of architecture and OS, x86_64-linux).

legacyPackages Explained

legacyPackages is a way for flakes to interact with the traditional, less structured package organization of nixpkgs. Instead of packages being directly at the top level (e.g., pkgs.hello), legacyPackages provides a platform-aware way to access them within the flake’s structured output format (e.g., nixpkgs.legacyPackages.x86_64-linux.hello). It acts as a bridge between the flake’s expected output structure and nixpkgs’s historical organization.

The Sole Argument of outputs

It’s crucial to remember that the outputs function accepts only one argument, which is an attribute set. The { self, nixpkgs, ... } syntax is simply destructuring that single input attribute set.

Outputs of the Flake (Return Value)

The outputs of the flake refer to the attribute set that is returned by the outputs function. This attribute set can contain various named outputs like packages, nixosConfigurations, devShells, etc.

Imports: Including Other Nix Expressions

The import function in Nix is used to evaluate the Nix expression found at a specified path (usually a file or directory) and return its value.
Basic Usage: import ./path/to/file.nix

Passing Arguments During Import

You can also pass an attribute set as an argument to the Nix expression being imported:

let
myHelpers = import ./lib/my-helpers.nix { pkgs = nixpkgs; };
in
# ... use myHelpers

In this case, the Nix expression in ./lib/my-helpers.nix is likely a function that expects an argument (often named pkgs by convention):

# ./lib/my-helpers.nix

{ pkgs }:
let
myPackage = pkgs.stdenv.mkDerivation {
name = "my-package"; # ...
};
in
myPackage

By passing { pkgs = nixpkgs; } during the import, you are providing the nixpkgs value from your current flake.nix scope to the pkgs parameter expected by the code in ./lib/my-helpers.nix.

Importing Directories (default.nix)

When you use import with a path that points to a directory, Nix automatically looks for a file named default.nix within that directory. If found, Nix evaluates the expressions within default.nix as if you had specified its path directly in the import statement.
