Whonix KVM on NixOS

⚠️ WARNING: There is no general software that can guarantee absolute anonymity or security; perfect security is a myth. Security is a continuous process, not a one-time product. It also depends on time and resources: if an adversary has enough of either, eventual compromise is possible. However, by layering defenses and following best practices, we can make attacks costly and time-consuming, deterring all but highly targeted adversaries.

Whonix offers many benefits, including the convenience of running within your current operating system without needing to reboot or use a separate Tails USB. It provides similar strong anonymity protections by routing all traffic through Tor in isolated virtual machines. The Whonix documentation is transparent about its limitations, which helps build trust and confidence in its security model.

• Whonix Compared to Tails

A Few Things to Consider when using Whonix

• You can anonymously use Java / Javascript

• No activity conducted inside Whonix-Workstation can cause IP/DNS leaks so long as Whonix-Gateway is left unchanged or only documented changes are made like configuring bridges, establishing onion services and running updates.

• Whonix does not and does not claim to protect users against advanced adversaries such as nation state actors, if they target you, you will be infected! If used correctly, Whonix can provide partial protection against passive surveillance programs, it all depends on whether Tor can provide adequate protection or not, which is not clear at this time.

• You shouldn't use a VPN with Whonix and it is obvious that you're using Tor because connections are made to known Tor Relays, which are publicly listed and identifiable.

⚠️It is impossible to Hide Tor use from the internet service provider (ISP). It has been concluded this goal is difficult beyond practicality. --Whonix Hide Tor from your ISP

• Millions of people use Tor daily for wholly legitimate reasons, particularly to assert their privacy rights when faced with countless corporate / government network observers and censors.

🔑 Key Terms

Whonix is an operating system based on Debian base (Kicksecure Hardened) and the Tor network, which is designed for maximum anonymity and security. Whonix consists of two Debian based VMs, the Whonix-Gateway and Whonix-Workstation.

In this case NixOS is the Host Operating System, NixOS runs the KVM kernel module, libvirtd service, and QEMU virtualization service which together enable hosting VMs.

Guests are the virtualized operating systems running inside the host's virtual machines. In this case the Whonix VMs are the Guest Machines.

Whonix-Gateway the first of 2 VMs runs Tor processes and forces all traffic through the Tor network using iptables.

Whonix-Workstation the second VM, is responsible for running user applications such as the Tor Browser. The Whonix-Workstation is isolated from both the Whonix-Gateway and the Host OS, if an app misbehaves, it is contained within the isolated Whonix-Workstation. It is largely unaware of sensitive info and won't leak unless an advanced adversary is able to break out of the VM.

The primary goal of Whonix is to be safer than Tor alone and that no one can find out the user's IP, location, or de-anonymize the user. It offers full spectrum anti-tracking protection that is much safer than VPNs. Whonix provides this through security by isolation, no app is trusted.

Whonix Concept: Whonix is an Isolating Proxy with an additional Transparent Proxy, which can be optionally disabled. --Whonix Docs

Since Whonix is based on Kicksecure which is based on Debian stable, you can typically look up solutions in a Kicksecure, Debian, or Ubuntu forum.

• The Whonix Team recommends KVM over VirtualBox for a number of reasons:Why choose KVM over VirtualBox

If you really want to use VirtualBox, I got it working off of this config:

# vbox.nix
{
  config,
  lib,
  ...
}: let
  cfg = config.custom.virtualbox;
in {
  options.custom.virtualbox = {
    enable = lib.mkEnableOption "Enable VirtualBox";
  };

  config = lib.mkIf cfg.enable {
    virtualisation.virtualbox.host = {
      enable = false;
      # enableExtensionPack = true;
    };

    user.user.your-user.extraGroups = ["vboxusers"];

    boot.kernelModules =
      if config.hardware.cpu.amd.updateMicrocode
      then ["kvm-amd"]
      else ["kvm-intel"];
  };
}

sudo lsmod | grep -E 'kvm|vbox'

modprobe -r kvm

sudo rmmod kvm_amd
sudo rmmod kvm
# To re-enable them when necessary
# sudo modprobe kvm
# sudo modprobe kvm_amd

Whonix-Gateway

The whonix-gateway is software designed to run Tor.

The Gateway acts as a firewall and is what is routing all your traffic through Tor.

You will spend minimal time in the Gateway, it's mainly used for Tor configuration which is reserved for advanced users.

Whonix-Workstation

All user applications should only be launched from Whonix-Workstation to ensure they utilize the Tor network. (Never launch the Tor browser or any other user app from Whonix-Gateway.)

Leaky applications can't breakout of the Workstation, all network connections are forced to go through the Whonix-Gateway where they are torrified and routed to the internet.

Whonix KVM (Kernel Virtual Machine) on NixOS

KVM (Kernel-based Virtual Machine) is a Linux kernel module that provides hardware-assisted virtualization.

It allows the Linux kernel to act as a hypervisor, enabling virtual machines (VMs) to run with near-native speeds by using CPU virtualization extensions (Intel VT-x or AMD-V).

KVM itself doesn’t handle the entire VM lifecycle; it provides the core virtualization infrastructure.

QEMU (Quick Emulator) is an open-source user-space program that emulates hardware for virtual machines.

When combined with KVM, QEMU uses hardware acceleration to run VMs much faster by offloading CPU virtualization to KVM.

So, QEMU provides the device emulation and VM management interface, while KVM provides the fast virtualization engine within the kernel.

Install Qemu-KVM:

{
  config,
  pkgs,
  ...
}: {
  ##  QEMU-KVM
  environment.systemPackages = with pkgs; [
    qemu
    # Optional
    virt-viewer
  ];

  # Virt-Manager GUI
  programs.virt-manager.enable = true;
  virtualisation = {
    # libvirtd daemon
    libvirtd = {
      enable = true;
      qemu = {
        # enables a TPM emulator
        swtpm.enable = true;
      };
    };
    # allow USB device to be forwarded
    spiceUSBRedirection.enable = true;
  };
  # Spice protocol improves VM display and input responsiveness
  services.spice-vdagentd.enable = true;
}

The libvirtd is the primary daemon (service) in the libvirt virtualization management system. It runs on your host machine and acts as the core management component for virtual machines (VMs).

Add libvirtd & kvm to your users extraGroups:

users.users = {
    your-user = {
        extraGroups = [
            "libvirtd"
            "kvm"
        ];
    };
};

Restart libvirtd:

sudo systemctl restart libvirtd

Network Start

Ensure KVM's / QEMU's default network is enabled and has started:

sudo virsh -c qemu:///system net-autostart default

sudo virsh -c qemu:///system net-start default

Download Whonix (KVM) (stable)

1. Whonix (KVM) (stable) Download

2. Go to whoniix.org to verify the signature.

3. Decompress the Image and follow the rest of the Whonix KVM install instructions from there.

Nixpkgs doesn't have the xz-utils package but it does have the xz package.

Nixpkgs also has nixpkgs.safe-rm if you wanted to follow the suggestions from Whonix.

nix-shell -p xz safe-rm

tar -xvf Whonix*.libvirt.xz

Import the Whonix VM Templates

• Follow steps 1 thru 3 in Importing Whonix VM Templates

After the above steps, either copy or move the qcow2 images to /var/lib/libvirt/images:

sudo mv Whonix-Gateway*.qcow2 /var/lib/libvirt/images/Whonix-Gateway.qcow2

sudo mv Whonix-Workstation*.qcow2 /var/lib/libvirt/images/Whonix-Workstation.qcow2

Launch virt-manager and start the VMs

virt-manager

Start Whonix-Gateway

Always start the Whonix-Gateway first.

Click on Whonix-Gateway, press Play, and choose the default Persistent VM.

To view the gateway press Open.

You can use the "System Maintenance Panel" to Check for Updates and then Install Updates. This can also be used for user and password creation, the default user is user with a passwordless login.

Change the password manually:

sudo passwd
changeme

• Whonix Common CLI Commands

Whonix-Workstation

Whonix-Workstation is another VM, designed to provide users with a secure and anonymous environment for running applications and performing online tasks.

When you first launch Whonix-Workstation, choose the second option down or reboot, and then choose "Persistent Mode Sysmaint Session".

With the workstation, a security feature disables sudo for the default user. Instead of the user account, a separate sysmaint (system maintenance) account is used for administrative tasks that require root privileges, such as updates and package installations.

Once Workstation is running and both VMs are updated and upgraded, check that your IP address is a Tor IP:

curl ip.me

Start Tor and check what you are fingerprinted as by typing deviceinfo.me into the URL.

Launching Tor Browser

Click the Xfce logo and choose Tor Browser. On the first launch, you will need to update Tor by clicking in the top right corner.

Or you can open the terminal and type:

update-torbrowser

Make sure you don't forget to go to the Settings, Privacy and Security, and set the Security Level to Safest to disable JavaScript and more before exploring the dark web.

If you need a place to start, check out tor.taxi by plugging that into the URL.
