Unencrypted Setups

Minimal BTRFS-Subvol Install with Disko and Flakes

Figure 1: BTRFS Logo: Image of the BTRFS logo. Sourced from the BTRFS repo

Why I Chose BTRFS

I chose BTRFS because I was already familiar with it from using it with Arch Linux and I found it to be very easy to use. From what I've read, there are licensing issues between the Linux Kernel and ZFS which means that ZFS is not part of the Linux Kernel; it's maintained by the OpenZFS project and available as a separate kernel module. This can cause issues and make you think more about your filesystem than I personally want to at this point.

If you have a ton of RAM you could most likely skip the minimal install and just set your system up as needed or just use tmpfs as root

Getting Started with Disko

Disko allows you to declaratively partition and format your disks, and then mount them to your system. I recommend checking out the README as it is a disk destroyer if used incorrectly.

We will mainly be following the disko quickstart guide

Figure 2: Disko Logo: Image of the logo for Disko, the NixOS declarative disk partitioning tool. Sourced from the Disko project

1. Get the Nixos Minimal ISO Get it on a usb stick, I use Ventoy with Ventoy2Disk.sh. The following is the link to the Ventoy TarBall download, untar it with tar -xzf ventoy-1.1.05-linux.tar.gz, and make it executable with chmod +x Ventoy2Disk.sh, and finally execute it with sudo bash Ventoy2Disk.sh Follow the prompts to finish the install.

2. The minimal installer uses wpa_supplicant instead of NetworkManager, to enable networking run the following:

sudo systemctl start wpa_supplicant
wpa_cli

> add_network
0

> set_network 0 ssid "myhomenetwork"
OK

> set_network 0 psk "mypassword"
OK

> enable_network 0
OK

To exit type quit, then check your connection with ping google.com.

Another option is to do the following, so either the above method or the below method after starting wpa_supplicant:

# Alternative for quick setup (less interactive, but often faster)
sudo wpa_passphrase "myhomenetwork" "mypassword" >> /etc/wpa_supplicant/wpa_supplicant-wlan0.conf
sudo systemctl restart wpa_supplicant@wlan0.service

3. Get your Disk Name with lsblk

The output should be something like:

NAME        MAJ:MIN RM   SIZE RO TYPE MOUNTPOINTS
nvme0n1     259:0    0   1,8T  0 disk

4. Copy the disk configuration to your machine. You can choose one from the examples directory.

• Option A: (Simpler for new users) I also created a starter repo containing much of what's needed. If you choose this option follow the README.md included with the repo.

cd ~
git clone https://github.com/saylesss88/my-flake.git

Make sure to change line 7 in disk-config.nix to what you got from step 3 device = "/dev/nvme0n1";

• Option B: (More flexible, more manual steps) Skip cloning the repo above and for the btrfs-subvolume default layout, run the following:

cd /tmp
curl https://raw.githubusercontent.com/nix-community/disko/refs/heads/master/example/btrfs-subvolumes.nix -o /tmp/disk-config.nix

5. Make Necessary changes, I set mine up for impermanence with the following:

nano /tmp/disk-config.nix

{
  disko.devices = {
    disk = {
      main = {
        type = "disk";
        device = "/dev/nvme0n1";
        content = {
          type = "gpt";
          partitions = {
            ESP = {
              priority = 1;
              name = "ESP";
              start = "1M";
              end = "512M";
              type = "EF00";
              content = {
                type = "filesystem";
                format = "vfat";
                mountpoint = "/boot";
                mountOptions = ["umask=0077"];
              };
            };
            root = {
              size = "100%";
              content = {
                type = "btrfs";
                extraArgs = ["-f"]; # Override existing partition
                # Subvolumes must set a mountpoint in order to be mounted,
                # unless their parent is mounted
                subvolumes = {
                  # Subvolume name is different from mountpoint
                  "/root" = {
                    mountpoint = "/";
                    mountOptions = ["subvol=root" "compress=zstd" "noatime"];
                  };
                  # Subvolume name is the same as the mountpoint
                  "/home" = {
                    mountOptions = ["subvol=home" "compress=zstd" "noatime"];
                    mountpoint = "/home";
                  };
                  # Sub(sub)volume doesn't need a mountpoint as its parent is mounted
                  "/home/user" = {};
                  # Parent is not mounted so the mountpoint must be set
                  "/nix" = {
                    mountOptions = [
                      "subvol=nix"
                      "compress=zstd"
                      "noatime"
                    ];
                    mountpoint = "/nix";
                  };
                  "/nix/persist" = {
                    mountpoint = "/nix/persist";
                    mountOptions = ["subvol=persist" "compress=zstd" "noatime"];
                  };
                  "/log" = {
                    mountpoint = "/var/log";
                    mountOptions = ["subvol=log" "compress=zstd" "noatime"];
                  };
                  "/lib" = {
                    mountpoint = "/var/lib";
                    mountOptions = ["subvol=lib" "compress=zstd" "noatime"];
                  };
                  # This subvolume will be created but not mounted
                  "/test" = {};
                };
              };
            };
          };
        };
      };
    };
  };
  fileSystems."/nix/persist".neededForBoot = true;
  fileSystems."/var/log".neededForBoot = true;
  fileSystems."/var/lib".neededForBoot = true;
}

• For /tmp on RAM use something like the following. I've found that having disko manage swaps causes unnecessary issues. Using zram follows the ephemeral route:

{
  lib,
  config,
  ...
}: let
  cfg = config.custom.zram;
in {
  options.custom.zram = {
    enable = lib.mkEnableOption "Enable utils module";
  };

  config = lib.mkIf cfg.enable {
    zramSwap = {
      enable = true;
      # one of "lzo", "lz4", "zstd"
      algorithm = "zstd";
       priority = 5;
       memoryPercent = 50;
    };
  };
}

And in your configuration.nix you would add:

# configuration.nix
custom = {
    zram.enable = true;
};

After adding the above module, you can see it with:

swapon --show
NAME       TYPE      SIZE USED PRIO
/dev/zram0 partition 7.5G   0B    5

6. Run disko to partition, format and mount your disks. Warning this will wipe EVERYTHING on your disk. Disko doesn't work with dual boot.

sudo nix --experimental-features "nix-command flakes" run github:nix-community/disko/latest -- --mode destroy,format,mount /tmp/disk-config.nix

Check it with the following:

mount | grep /mnt

The output for an nvme0n1 disk would be similar to the following:

#... snip ...
/dev/nvme0n1p2 on /mnt type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=285,subvol=/root)
/dev/nvme0n1p2 on /mnt/persist type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=261,subvol=/persist)
/dev/nvme0n1p2 on /mnt/etc type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=261,subvol=/persist)
/dev/nvme0n1p2 on /mnt/nix type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=260,subvol=/nix)
/dev/nvme0n1p2 on /mnt/var/lib type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=258,subvol=/lib)
/dev/nvme0n1p2 on /mnt/var/log type btrfs (rw,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=259,subvol=/log)
/dev/nvme0n1p2 on /mnt/nix/store type btrfs (ro,noatime,compress=zstd:3,ssd,discard=async,space_cache=v2,subvolid=260,subvol=/nix)
# ... snip ...

7. Generate necessary files, here we use --no-filesystems because disko handles the fileSystems attribute for us.

nixos-generate-config --no-filesystems --root /mnt

It may be helpful to add a couple things to your configuration.nix now, rebuild and then move on. Such as, your hostname, git, an editor of your choice. After your additions run sudo nixos-rebuild switch to apply the changes. If you do this, you can skip the nix-shell -p command coming up.

sudo mv /tmp/disk-config.nix /mnt/etc/nixos

Setting a Flake for your minimal Install

8. Create the flake in your home directory, then move it to /mnt/etc/nixos. This avoids needing to use sudo for every command while in the /mnt/etc/nixos directory.

cd ~
mkdir flake && cd flake
nix-shell -p git yazi helix
export NIX_CONFIG='experimental-features = nix-command flakes'
export EDITOR='hx'
hx flake.nix

You'll change hostname = nixpkgs.lib.nixosSystem to your chosen hostname, (e.g. magic = nixpkgs.lib.nixosSystem). This will be the same as your networking.hostName = "magic"; in your configuration.nix that we will set up shortly.

# flake.nix
{
  description = "NixOS configuration";

  inputs = {
    nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";
    disko.url = "github:nix-community/disko/latest";
    disko.inputs.nixpkgs.follows = "nixpkgs";
    # impermanence.url = "github:nix-community/impermanence";
  };

  outputs = inputs@{ nixpkgs, ... }: {
    nixosConfigurations = {
      hostname = nixpkgs.lib.nixosSystem {
        system = "x86_64-linux";
        modules = [
          ./configuration.nix
          inputs.disko.nixosModules.disko
          # inputs.impermanence.nixosModules.impermanence
        ];
      };
    };
  };
}

Move all the files into your flake:

cd /mnt/etc/nixos/
sudo mv disk-config.nix hardware-configuration.nix configuration.nix ~/flake

9. Edit configuration.nix with what is required, the following is required, I clone my original flake repo and move the pieces into place but it's fairly easy to just type it all out:

• Bootloader, (e.g., boot.loader.systemd-boot.enable = true;)

• User, the example uses username change this to your chosen username. If you don't set your hostname it will be nixos.

• Networking, networking.networkmanager.enable = true;

• hardware-configuration.nix & disk-config.nix for this setup

• initialHashedPassword: Run mkpasswd -m SHA-512 -s, then enter your desired password. Example output,

Password: your_secret_password
Retype password: your_secret_password
$6$random_salt$your_hashed_password_string_here_this_is_very_long_and_complex

copy the hashed password and use it for the value of your initialHashedPassword

# configuration.nix
{
  config,
  lib,
  pkgs,
  inputs,
  ...
}: {
  imports = [
    # Include the results of the hardware scan.
    ./hardware-configuration.nix
    ./disk-config.nix
  ];

  networking.hostName = "magic"; # This will match the `hostname` of your flake

  networking.networkmanager.enable = true;

  boot.loader.systemd-boot.enable = true; # (for UEFI systems only)
  # List packages installed in system profile.
  # You can use https://search.nixos.org/ to find more packages (and options).
  environment.systemPackages = with pkgs; [
    vim # Do not forget to add an editor to edit configuration.nix! The Nano editor is also installed by default.
    #   wget
    git
  ];

  time.timeZone = "America/New_York";

  users.users.nixos = {
    isNormalUser = true;
    extraGroups = [ "wheel" "networkmanager" ]; # Add "wheel" for sudo access
    initialHashedPassword = "COPY_YOUR_MKPASSWD_OUTPUT_HERE"; # <-- This is where it goes!
    # home = "/home/nixos"; # Optional: Disko typically handles home subvolumes
  };

  console.keyMap = "us";

  nixpkgs.config.allowUnfree = true;

  system.stateVersion = "25.05";
}

10. Move the flake to /mnt/etc/nixos and run nixos-install:

sudo mv ~/flake /mnt/etc/nixos/
sudo nixos-install --flake /mnt/etc/nixos/flake .#hostname
# if the above command doesn't work try this:
sudo nixos-install --flake /mnt/etc/nixos/flake#hostname

• You will be prompted to enter a new password if everything succeeds.

• If everything checks out, reboot the system and you should be prompted to enter your user and password to login to a shell to get started.

• The flake will be placed at /etc/nixos/flake, I choose to move it to my home directory. Since the file was first in /etc you'll need to adjust the permissions with something like sudo chown username:users ~/flake(username will be your username) and then you can work on it without privilege escalation.

• You can check the layout of your btrfs system with:

sudo btrfs subvolume list /

• You may notice some old_roots in the output, which are snapshots, which are likely created before system upgrades or reboots for rollback purposes. They can be deleted or rolled back as needed.

• BTRFS Subvolumes

• To continue following along and set up impermanence Click Here
