Extending Flakes with Custom Packages using Overlays

✔️ Click to Expand Table of Contents

Pokego Logo–pokego repo

Overlays are Nix functions that accept two arguments, final and prev and return a set of packages. Overlays are similar to packageOverrides as a way to customize Nixpkgs, packageOverrides acts as an overlay with only the prev argument. Therefore, packageOverrides is appropriate for basic use, but overlays are more powerful and easier to distribute.

Example:

final: prev: {
  firefox = prev.firefox.overrideAttrs (old: {
    buildInputs = (old.buildInputs or []) ++ [ prev.vlc ];
    env.FIREFOX_DISABLE_GMP_UPDATER = "1";
  });
}

To see the original derivation, run nix edit -f "<nixpkgs>" firefox.

This modifies Firefox by:

  • Adding vlc to buildInputs, useful if a package requires additional dependencies.

  • Setting an environment variable (FIREFOX_DISABLE_GMP_UPDATER=1) to disable automatic updates of the Gecko Media Plugin.

It is very common to use overlays in Nix to install packages that aren’t available in the standard Nixpkgs repository.

Overlays are one of the primary and recommended ways to extend and customize your Nix environment. It’s important to remember that Nix overlays are made to allow you to modify or extend the package set provided by Nixpkgs (or other Nix sources) without directly altering the original package definitions. This is crucial for maintaining reproducibility and avoiding conflicts. Overlays are essentially functions that take the previous package set and allow you to add, modify, or remove packages.

  • To better understand the structure of my flake.nix it may be helpful to first read This blog post first.

Adding the overlays output to your Flake

I’ll show the process of adding the pokego package that is not in Nixpkgs:

  1. In my flake.nix I have a custom inputs variable within my let block of my flake like so just showing the necessary parts for brevity:
# flake.nix
  outputs = my-inputs @ {
    self,
    nixpkgs,
    treefmt-nix,
    ...
  }: let
    system = "x86_64-linux";
    host = "magic";
    userVars = {
      username = "jr";
      gitUsername = "saylesss88";
      editor = "hx";
      term = "ghostty";
      keys = "us";
      browser = "firefox";
      flake = builtins.getEnv "HOME" + "/flake";
    };

    inputs =
      my-inputs
      // {
        pkgs = import inputs.nixpkgs {
          inherit system;
        };
        lib = {
          overlays = import ./lib/overlay.nix;
          nixOsModules = import ./nixos;
          homeModules = import ./home;
          inherit system;
        };
      };
      # ... snip ...
  • Why I Created inputs.lib in My flake.nix. In the above example, you’ll notice a lib attribute defined within the main let block.

    • This might seem a bit unusual at first, as inputs are typically defined at the top level of a flake. However, this structure provides a powerful way to organize and reuse common Nix functions and configurations across my flake.

    • By bundling my custom logic and modules into inputs.lib, I can pass inputs (which now includes my custom lib) as a specialArgs to other modules. This provides a clean way for all modules to access these shared resources. For example, in configuration.nix, inputs.lib.overlays directly references my custom overlay set.

    • My inputs.lib is my own project-specific library, designed to hold functions and attribute sets relevant to my flake’s custom configurations. While nixpkgs.lib is globally available, my custom lib contains my unique additions.

While defining inputs within the let block to achieve this structure is a personal preference and works well for my setup, the core benefit is the creation of a dedicated, centralized lib attribute that encapsulates my flake’s reusable Nix code, leading to a more organized and maintainable configuration.

The Actual Overlay

  1. In the overlay.nix I have this helper function and the defined package:
# overlay.nix
_final: prev: let
  # Helper function to import a package
  callPackage = prev.lib.callPackageWith (prev // packages);

  # Define all packages
  packages = {
    # Additional packages
    pokego = callPackage ./pac_defs/pokego.nix {};
  };
in
  packages
  1. _final: prev:: This is the function definition of the overlay.

  • _final: This argument represents the final, merged package set after all overlays have been applied. It’s often unused within a single overlay, hence the _ prefix (a Nix convention for unused variables).

  • prev: This is the crucial argument. It represents the package set before this overlay is applied. This allows you to refer to existing packages and functions from Nixpkgs.

  1. let ... in packages: This introduces a let expression, which defines local variables within the scope of this overlay function. The in packages part means that the overlay function will ultimately return the packages attribute set defined within the let block.

  2. callPackage = prev.lib.callPackageWith (prev // packages): This line defines a helper function called callPackage.

  • prev.lib.callPackageWith Is a function provided by Nixpkgs’ lib. callPackageWith is like prev.lib.callPackage, but allows the passing of additional arguments that will then be passed to the package definition.

  • (prev // packages): This is an attribute set merge operation. It takes the prev package set (Nixpkgs before this overlay) and merges it with the packages attribute set defined later in this overlay.

  • By using callPackageWith with this merged attribute set, the callPackage function defined here is set up to correctly import package definitions, ensuring they have access to both the original Nixpkgs and any other packages defined within this overlay.

  1. packages = { ... };: This defines an attribute set named packages. This set will contain all the new or modified packages introduced by this overlay.

  2. pokego = callPackages ./pac_defs/pokego.nix { };: This is the core of how the pokego package is added.

  • pokego =: This defines a new attribute named pokego within the packages attribute set. This name will be used to refer to the pokego package later.

  • callPackage ./pac_defs/pokego.nix {}: This calls the callPackage helper function defined earlier.

  • ./pac_defs/pokego.nix: This is the path to another Nix file(pokego.nix) that contains the actual package definition for pokego. This file would define how to fetch, build, and install the pokego software

  • {}: This is an empty attribute set passed as additional arguments to the pokego.nix package definition. If pokego.nix expected any specific parameters (like versions or dependencies), you would provide them here. Since it’s empty, it implies pokego.nix either has no required arguments or uses default values.

  1. in packages: As mentioned earlier, the overlay function returns the packages attribute set. When this overlay is applied, the packages defined within this packages set (including pokego) will be added to the overall Nix package set.

The pokego Package definition

The following is the ./pac_defs/pokego.nix:

# pokego.nix
{
  lib,
  buildGoModule,
  fetchFromGitHub,
}:
buildGoModule rec {
  pname = "pokego";
  version = "0.3.0";

  src = fetchFromGitHub {
    owner = "rubiin";
    repo = "pokego";
    rev = "v${version}";
    hash = "sha256-cFpEi8wBdCzAl9dputoCwy8LeGyK3UF2vyylft7/1wY=";
  };

  vendorHash = "sha256-7SoKHH+tDJKhUQDoVwAzVZXoPuKNJEHDEyQ77BPEDQ0=";

  # Install shell completions
  postInstall = ''
    install -Dm644 completions/pokego.bash "$out/share/bash-completion/completions/pokego"
    install -Dm644 completions/pokego.fish "$out/share/fish/vendor_completions.d/pokego.fish"
    install -Dm644 completions/pokego.zsh "$out/share/zsh/site-functions/_pokego"
  '';

  meta = with lib; {
    description = "Command-line tool that lets you display Pokémon sprites in color directly in your terminal";
    homepage = "https://github.com/rubiin/pokego";
    license = licenses.gpl3Only;
    maintainers = with maintainers; [
      rubiin
      jameskim0987
      vinibispo
    ];
    mainProgram = "pokego";
    platforms = platforms.all;
  };
}

Adding the overlay to your configuration

There are a few places you could choose to put the following, I choose to use my configuration.nix because of my setup:

# configuration.nix
nixpkgs.overlays = [inputs.lib.overlays]

Installing Pokego

  • If you are managing your entire system configuration with NixOS, you would typically add pokego to your environment.systemPackages.
# configuration.nix
environment.systemPackages = with pkgs; [
  pokego
]
  • If you prefer home-manager you can install pokego with home-manager also:
# home.nix
home.packages = [
  pkgs.pokego
]

Another Overlay Example

{
  inputs = {
    nixpkgs.url = "https://flakehub.com/NixOS/nixpkgs/*.tar.gz";

    nix.url = "https://flakehub.com/f/NixOS/nix/2.17.0.tar.gz";
  };

  outputs = { self, nixpkgs, nix }:

    let
      system = "aarch64-darwin";
      pkgs = import nixpkgs {
        inherit system;
        overlays = [
          nix.overlays.default
        ];
      };
    in
    {
     # `pkgs` is nixpkgs for the system, with nix's overlay applied
    };
}

  • Normally, pkgs = import nixpkgs { }`` imports Nixpkgs with default settings. However, the example above customizes this import by passing arguments: pkgs = import nixpkgs { inherit system; overlays = [ nix.overlays.default];}. This makes the pkgs variable represent nixpkgs specifically for the aarch64-darwin` system, with the overlay from the nix flake applied.

  • Consequently, any packages built using this customized pkgs will now depend on or use the specific nix version (2.17.0) provided by the nix flake, instead of the version that comes with the fetched nixpkgs. This technique can be useful for ensuring a consistent environment or testing specific package versions.

Customizing Nixpkgs Imports and Overlays

While overlays are typically used to add or modify packages within a single nixpkgs instance, Nix’s lazy evaluation and flake inputs allow for even more powerful scenarios. You can have multiple versions of nixpkgs in a single flake, and they will only be evaluated when a package from that specific version is actually referenced. This complements overlays by giving you fine-grained control over which nixpkgs instance an overlay applies to, or which nixpkgs version a specific part of your project depends on.

Consider this example where we import nixpkgs with a specific overlay applied directly at the import site:

{
  inputs = {
    nixpkgs.url = "[https://flakehub.com/NixOS/nixpkgs/*.tar.gz](https://flakehub.com/NixOS/nixpkgs/*.tar.gz)"; # This will be the base nixpkgs

    nix.url = "[https://flakehub.com/f/NixOS/nix/2.17.0.tar.gz](https://flakehub.com/f/NixOS/nix/2.17.0.tar.gz)"; # This flake provides an overlay for a specific Nix version
  };

  outputs = { self, nixpkgs, nix }:

    let
      system = "aarch64-darwin";
      # Here, we import nixpkgs and apply the 'nix' flake's overlay.
      # This 'pkgs' variable now holds a customized Nix package set.
      # In this 'pkgs' set, the 'nix' package (and anything that depends on it)
      # will be version 2.17.0 as defined by the 'nix' flake's overlay.
      pkgs_with_custom_nix = import nixpkgs {
        inherit system;
        overlays = [
          nix.overlays.default # Apply the overlay from the 'nix' flake here
        ];
      };
    in
    {
      # We can then expose packages or devShells that use this customized `pkgs` set.
      devShells.${system}.default = pkgs_with_custom_nix.mkShell {
        packages = [
          pkgs_with_custom_nix.nix # This 'nix' package is now version 2.17.0 due to the overlay!
        ];
        shellHook = ''
          echo "Using Nix version: <span class="math-inline">\(nix \-\-version\)"
'';
};
# You can also make this customized package set available as a top-level overlay
# if other parts of your flake or configuration want to use it.
# overlays.custom-nix-version = final: prev: {
#   inherit (pkgs_with_custom_nix) nix; # Expose the specific nix package from our overlayed pkgs
# };
# You can also import multiple versions of nixpkgs and select packages from them:
# pkgs-2505 = import (inputs.nixpkgs-2505 or nixpkgs) { inherit system; }; # Example, assuming 2505 is an input
# packages.</span>{system}.my-tool-2505 = pkgs-2505.myTool; # Using a package from a specific stable version
    };
}

Normally, pkgs = import nixpkgs { } imports Nixpkgs with default settings. However, the example above customizes this import by passing arguments: pkgs = import nixpkgs { inherit system; overlays = [ nix.overlays.default];}. This makes the pkgs_with_custom_nix variable represent Nixpkgs specifically for the aarch64-darwin system, with the overlay from the nix flake applied at the time of import.

Consequently, any packages built using this customized pkgs_with_custom_nix will now depend on or use the specific Nix version (2.17.0) provided by the nix flake’s overlay, instead of the version that comes with the base nixpkgs input. This technique is highly useful for ensuring a consistent environment or testing specific package versions without affecting the entire system’s nixpkgs set.
